Bloque de soporte
Bloque de cojinetes de apoyo, Montaje con base y brida, M50 x 1.5 , diámetros compatibles:2.500 in, 63 mm
Plazo:
2 semanas
Con pedidos de mayores cantidades, los plazos de entrega pueden extenderse. Los plazos de entrega se muestran en días hábiles.
| Dimension | Valor |
|---|---|
| A | 905.000,00 mm (35.629,921 in) |
| B | 1.150.000,00 mm (45.275,591 in) |
| C | 2.300.000,00 mm (90.551,181 in) |
| D | 235.000,00 mm (9.251,969 in) |
| D2 | 1.080.000,00 mm (42.519,685 in) |
| D3 | 500.000,00 mm (19.685,039 in) |
| F | 908.000,00 mm (35.748,031 in) |
| G | 1.130.000,00 mm (44.488,189 in) |
| J | 920.000,00 mm (36.220,472 in) |
| K | 714.500,00 mm (28.129,921 in) |
| L | 1.430.000,00 mm (56.299,213 in) |
| M | 6x 20.63 dia |
| N | 4x 26.19 Thru, 41.28 C-Bore x |
| P | 22.900,00 mm (901,575 in) |
| Q | 1.244.600,00 mm (49.000,000 in) |
| R | 461.000,00 mm (18.149,606 in) |
| S | 1.970.000,00 mm (77.559,055 in) |
| T | 1.240.000,00 mm (48.818,898 in) |
| TH | KM-10 |
| U (Min) | 393.770,00 mm (15.502,756 in) |
| U (Max) | 400.000,00 mm (15.748,031 in) |
| V (Min) | 499.970,00 mm (19.683,858 in) |
| V (Max) | 500.100,00 mm (19.688,976 in) |
| W | 1.080.000,00 mm (42.519,685 in) |
| X | 100.000,00 mm (3.937,008 in) |
| Y | 650.000,00 mm (25.590,551 in) |
