195-9722
Can't find what you're looking for? Go to the Product Selector
Ball Screw
Ball Screw, 32 mm X 32 mm, Thread Direction: Right Hand, ±23 µm/300mm, Number Of Starts: 4
Lead Time:
2 Weeks
Lead times may increase with higher quantities. Lead time displayed in business days.
Cut to Length:
Min: 26.0 mm Max: 6000.0 mm Tolerance +/- 1 mm
- For custom machined screws, please submit a drawing or description for a quotation on a machined screw or screw and nut assembly.
- Screw only, No Ball nut
- Machined screws can be ordered with Ball Nuts and Support Bearings under the Ball Screw/Nut Assembly section, here.
- *See Related Products for compatible ball nut options
| Dimension | Value |
|---|---|
| D1 | 31.30 mm (1.232 in) |
| D2 | 28.33 mm (1.115 in) |
| D3 | 25.00 mm (0.984 in) |
